12 1/4"(311.1mm)537G TCI Roller Cone Bits with Chisel Tungsten Carbide Inserts
NAME

12 1/4"(311.1mm)537G TCI Roller Cone Bits with Chisel Tungsten Carbide Inserts

Summary information
12 1/4 inches TCI Tricone Bit
Affiliate classification
TCI Tricone Bit
share：facebook twitter linkedin
没有此类产品
Description

API Certified factory of Tricone Bits and PDC bits
API is American Petroleum Institute, it is Authoritative in the world.
All products are produced in lines of API specifications.
TCI Roller
SOLIDKEY
TCI Roller TCI Roller

Specifications
Diameter  12 1/4"(311.1mm)
Bearing Type  Elastomer sealed bearing
Tooth Type  TCI(Tungsten Carbide Inserts)
Circulation Type  Mud fluid
Thread Connection  6 5/8 reg pin
Gauge Protection  Available
Shirttail Protection  Available
Operating Parameters
RPM(r/min) 120-50
WOB(KN) 140-311
Formations Medium formations,such as medium shale,limestone, medium sandstone,medium formation with harder and abrasive interbeds,etc.



12 1/4 inches tricone bit is widely used in drilling projects, oil&gas well drilling, geothermal well drilling, water well drilling, and trenchless drilling,. IADC537G is suitable for drilling medium hardness rocks, like limestone, shale, sandstone, etc.

Drillers use it as integral tri-cone bits, or split it into 3 segment(thirds, 1/3) to weld it on trenchless hole opener, foundation rock piling core barrel.

In water and geothermal well drilling fields, elastomer sealed bearing is recommended to achieve high cost-performance. Premium O-ring sealing, pressure compensation system and specific grease can greatly increase the reliability of bearing.

12 1/4" IADC537G is a popular size and hot selling model tricone bits in the world.



Regular Models

TCI Roller TCI Roller TCI Roller
8 1/2"(215.9mm) IADC537G 8 1/2"(215.9mm) IADC637G 12 1/4"(311.1mm) IADC537G
TCI Roller TCI Roller TCI Roller
9 7/8"(250.8mm) IADC637G 9 7/8"(250.8mm) IADC617G 12 1/4"(311.1mm) IADC637G

TCI Roller		 TCI Roller TCI Roller
17 1/2" (444.5mm) IADC537G 17 1/2"(444.5mm) IADC637G 16"(406.4mm) IADC517G
TCI Roller
 		 TCI Roller TCI Roller
14 3/4"(374.7mm) IADC537G 10 5/8"(269.8mm) IADC537G 9 7/8"(250.8mm) IADC537G
TCI Roller TCI Roller TCI Roller
7 7/8"(200.0mm) IADC537G 6 1/2"(165.1mm) IADC637G 4 1/2"(114.3mm) IADC537G
TCI Roller TCI Roller TCI Roller
12 1/4"(311.1mm) IADC137G 9 7/8"(250.8mm) IADC127G 4 5/8"(117.4mm) IADC216G
TCI Roller TCI Roller TCI Roller
12 1/4"(311.1mm) PDC Bit 6"(152.4mm) PDC Bit Bi Center Bit
TCI Roller TCI Roller TCI Roller
44" Hole Opener 36" Hole Opener 24" Hole Opener
TCI Roller TCI Roller TCI Roller
HDD PDC Reamer 18" PDC Reamer 14" PDC Reamer
TCI Roller TCI Roller TCI Roller
Tricone Bit Thirds Block Roller Bits Block Roller Bits
TCI Roller TCI Roller TCI Roller
Roller Cone Bits for Piling Replaceable Roller Cone Bits Core Barrel



Applications

Oil/Gas Well Drilling-Water Well Drilling-HDD(Trenchless)-Foundation Piling

TCI Roller





Our Mission:
Lower the cost of Drilling-Per-Meter.

Who we are:
To exploit energy resources underground.
To exploit water underground.
To install pipelines underground with No-Dig.
To pile foundation for constructions.
We are one of the people who makes above easier.
Let’s work together and enjoy this job.
